[ TECHNICAL DATASHEET ]
RoboWrangler™ 2000 · IRONCLAW™ — Full Datasheet.
Engineering specifications, drive system, operating envelope, and certifications. Field-measured. Rev 2026.05.
// DOC: PR-CW2000-DS · REV 2026.05 · STATUS: RELEASED
[ 01 — ROBOWRANGLER™ 2000 ]
// 15 PARAMETERS// PARAMETER
// VALUE
JOB TYPE
MINOR WORKOVER
tubing & sucker rods
ARM REACH
23.6 FT
7.2 m
LIFTING HEIGHT
30.35 FT
9.25 m
MAX GRIPPING PAYLOAD
882 LB
400 kg
GRIPPING DIAMETER
Ø ≤ 3.5 IN
Ø ≤ 89 mm
PIPE TYPES HANDLED
TUBING · SUCKER RODS
WORKER PLATFORM HEIGHT
3.28 FT
1 m
LINEAR SLIDE STROKE
16.4 FT
5 m
PIPE LAYOUT WIDTH
32.8 FT
10 m
MOBILITY
CRAWLER + OUTRIGGERS
rolls between wells
CRAWLER TRAVEL SPEED
65.6 FT/MIN
20 m/min
CLIMBING ANGLE
≤ 5°
grade-rated
RATED VOLTAGE / POWER
380 V · 50.3 HP
37.5 kW · US 480V/60Hz available
OPERATING TEMP
−4 °F → 131 °F
−20 °C → 55 °C
GROSS WEIGHT
50,706 LB
23 metric tons
TRANSPORT FOOTPRINT
28.4 × 11.2 × 7.5 FT
8.65 × 3.4 × 2.3 m (L×H×W)
WORKING FOOTPRINT
37.9 × 30.35 × 14.6 FT
11.57 × 9.25 × 4.45 m
DRIVE
ALL-ELECTRIC
explosion-proof envelope
[ 02 — IRONCLAW™ ELECTRIC POWER TONG ]
// 6 PARAMETERS// PARAMETER
// VALUE
DRIVE
ALL-ELECTRIC
no hydraulic system
TORQUE CONTROL
CLOSED-LOOP
continuous regulation
OPERATING MODE
RAPID + PRECISION
selectable
CYCLE UPLIFT
>50%
vs. manual makeup/breakout
SAFETY
OVERLOAD TRIP
anti-misoperation logic
INTEGRATION
NATIVE + STANDALONE
RoboWrangler workstation
